INPUT - Nominal Voltage : 200/208/220/230/240VAC - Input Voltage Range : 110-300 VAC (Based on load at 50%) ; 160-280 VAC (Based on load at 100%) - Frequency Range : 40 Hz - 70 Hz - Power Factor : ≧ 0.99 @ Nominall Voltage (100% load) OUTPUT - Output Voltage : 200/208/220/230/240VAC - Voltage Regulation : ± 1 % - Frequency Range (Synchronized Range): 47~53 Hz or 57~63 Hz - Frequency Range (Batt. Mode): 50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz - Current Crest Ratio : 3:1 - Harmonic Distortion : ≦ 3 % THD (Linear Load) ; ≦ 5 % THD (Non-linear Load) - Transfer Time : AC Mode to Battery Mode : Zero ; Inverter to Bypass : 4ms (Typical) - Waveform (Batt. Mode) : Pure Sinewave EFFICIENCY - AC Mode : 88% - Battery Mode : 83% BATTERY - Standard Model : 27.4VDC ± 1 %
Berhasil ditambahkan
Harga Rp.9.100.000 Jumlah
